Nickel Alloy 2200 | Nickel Alloy | Seamless Tubes Nickel Alloy | Nickel Alloy
200 Manufacturer | Manufacturer of Nickel Alloy
Kanakratna steelage is a renowned exporter,
manufacturer, stockist, supplier, and stockholder of high-quality Nickel
Alloy Seamless Tubes. These tubes are celebrated for their excellent
corrosion resistance, high-temperature strength, and durability, making them
ideal for applications in aerospace, chemical processing, power generation,
and marine industries. Nickel alloy tubes maintain their mechanical
properties across a wide temperature range, ensuring consistent performance
in demanding environments. Additionally, they offer superb weldability and
ease of fabrication, making them a reliable choice for a variety of critical
applications.
Nickel 200 Pipe is made up of a commercially
pure grade of nickel. This is a
wrought product that has good strength and very high corrosion resistant
properties. The material also has very low electrical resistance. Steel
India Company is a leading manufacturer and supplier of the Nickel Alloy 200
Pipe products in various dimensions and types. The material is resistant
against many agents, especially to hydroxides. The specifications for the
Nickel 200 Seamless Pipe are ASTM B161 and B622 with the dimensions varying
according to the ASTM, ASME and API standards.
Technical Specifications
| CHEMICAL COMPOSITION
(% by weight) |
|
Element
|
Min
|
Max
|
|
Ni
|
99
|
-
|
|
Cu
|
-
|
0.25
|
|
S
|
-
|
0.01
|
|
Cu
|
-
|
0.25
|
|
C
|
-
|
0.15
|
|
Fe
|
-
|
0.40
|
|
Si
|
-
|
0.35
|
| MECHANICAL PROPERTIES |
|
Temper
|
Annealed
|
|
Tensile Rm
|
67
|
ksi (min) |
|
Tensile Rm
|
462
|
MPa (min) |
|
R.p. 0.2% Yield
|
21.5
|
ksi (min) |
|
R.p. 0.2% Yield
|
148
|
MPa (min) |
|
Elongation (2” or 4D gl)
|
47
|
% (min) |
| PHYSICAL PROPERTIES (Room Temperature) |
|
Melting Range
|
2615 – 2635
|
°F
|
1435 – 1446
|
°C
|
|
Specific Heat
|
0.109
|
Btu/lb•°F
|
456
|
J/kg•°C
|
|
Curie Temperature
|
680
|
°F
|
360
|
°C
|
|
Coefficient of Expansion
|
7.4
|
70 – 200°F, 10-6 in/in•°F
|
13.3
|
21 – 93°C, µm/m•°C
|
|
Thermal Conductivity
|
487
|
Btu • in/ft2 •h•°F
|
70.2
|
W/m • °C
|
|
Electrical Resistivity
|
58
|
ohm • circ mil/ft
|
0.096
|
µΩ•m
|
|
Density
|
0.321
|
Ib/in3
|
8.89
|
g/cm3
|
|
Coefficient of Expansion
|
Ferromagnetic
|
